Output voltage at 1 kHz 5 cm/sec: 0.5 mV
Channel balance: < 1.5 dB
Channel separation at 1 kHz: > 21 dB
Channel separation at 15 kHz: > 14 dB
Frequency range at -3 dB: 20 - 25.000Hz
Frequency response 20-20.000 Hz: +/-2.5 dB
Tracking ability at 315 Hz at recommended tracking force *): 70 µm
Compliance, dynamic, lateral: 15 µm/mN
Stylus type: Nude Elliptical
Stylus tip radius: r/R 8/18 µm
Tracking force range: 2.1-2.5 g (21-25 mN)
Tracking force recommended: 2.3 g (23 mN)
Tracking angle: 20º
Internal impedance, DC resistance: 7 Ohm
Recommended load impedance: >20 Ohm
Cartridge body material: ABS/Aluminium
Coil wire material: Pure 4-nines copper
Cartridge colour: Blue
Cartridge weight: 9 g
