- Output voltage at 1000 Hz, 5cm/sec.: 5 mV
- Channel balance at 1 kHz: 1 dB
- Channel separation at 1 kHz: 26 dB
- Channel separation at 15 kHz: 15 dB
- Frequency range at - 3dB: 20-29.000 Hz
- Frequency response: 20-20.000 Hz + 2 / - 0 dB
- Tracking ability at 315Hz at recommended tracking force: 80 µm
- Compliance, dynamic, lateral: 22 µm/mN
- Stylus type: Nude Fine Line
- Stylus tip radius: r/R 8/40 µm
- Tracking force range: 1,4-1,7g (14-17 mN)
- Tracking force, recommended: 1,5 g (15 mN)
- Tracking angle: 20º
- Internal impedance, DC resistance: 1,2 kOhm
- Internal inductance: 630 mH
- Recommended load resistance: 47 kOhm
- Recommended load capacitance: 150-300 pF
- Cartridge colour, body/stylus: Black/Bronze
- Cartridge weight: 7,2 g
- Replacement stylus unit: 2M Bronze (interchangeable with 2M Black)
|
